Optoplast 905 SMA Connector, 144µm (micron) Ceramic Ferrule, 3mm Black Boot

Optoplast SMA fiber optic connectors are the longest-standing optical connector standard and feature a threaded plug-and-socket design. The SMA connector is not torsion-proof, so the fibers of two connectors cannot make direct physical contact without risking damage. Instead, the ferrules establish contact while keeping the fiber end surfaces separated. While primarily designed for multimode fibers, the SMA connector can also support single-mode fibers. Its robust design makes it ideal for use in medical and military applications.

Features:

• Ferrule ID: 144µm (micron)
• Ferrule Type: Ceramic (Zirconia)
• Boot Size: 3mm
• Boot Color: Black
• ID Tolerance: ≤5
• Concentricity: ≤10

Mechanical Characteristics:

• Mating Durability: >500 Connections
• Cable Retention: 100 N, 120s
• 900 μm Buffer Retention: 5 N, 60 s
• Vibration: 10 to 55 Hz, 1 octave/min: 3 axis of 15 cycles, 0.5 h/axis, amplitude 0.75 mm
• Repeated Bending Cable: 100 cycles -90°/0°/+90°/0° 5 N Load
• Repeated Bending 900μm Buffer: 100 cycles -90°/0°/+90°/0° 0.2 N Load
• Cable Torsion: 1.5 to 2.5 kg for 2 to 3 mm cable diameter
• Drop: 1.5 m, 5 times
• Static Side Load: 1 N, 1 h
• Static Side Load 900 μm Buffer: 0.2 N, 5 min
• Temperature: -25°C to +70°C (-13°F to 158°F), 12 cycles
