AFL 120 Fiber Loose Tube 2x Jacket SM

AFL’s Non-Armored Loose Tube fiber optic cables are designed to provide high fiber counts with the flexibility and versatility required for today’s most demanding installations. With fiber counts up to 576 and S-Z strand designs for easy mid-span access, AFL’s cables comply with EIA/TIA, REA/RUS PE-90 and GR-20. Industry-standard designs combined with innovative technologies, such as a dry core product, yield a world-class cable that will support today’s and tomorrow’s technological needs.

Temperature Range
Operating: -40ºC to +70ºC
Storage: -40ºC to +75ºC
Installation: -30ºC to +70ºC

Fiber Count: 120
Number of Tubes/Fibers: 10w/12 (no fillers)
Nominal Diameter: 0.59 inches
Nominal Weight: 99 lbs/1,000ft
