AFL RS03 Thermal Fiber Stripper for up to 16-Fiber Ribbon, Battery-Powered

The AFL RS03 Thermal Stripper delivers superior performance for single and multi-fiber stripping. With a fast 3-second heating time, it maximizes productivity. Ergonomic design and low pulling force make it comfortable and easy to use for high fiber count applications. The RS03 optical fiber stripper handles 200 μm coated fibers and ribbons, with an audible beep and LED indicating when the proper temperature is reached. A temperature selection switch allows easy optimization for different fibers or operating conditions. Compatible with all Fujikura field and factory-style fiber holders.

Bluetooth® capability lets users program the RS03 via an Android or iOS smartphone app for personalized operation. Its powerful Lithium-Ion battery provides enough power for approximately 600 stripping cycles.

RS03 Thermal Stripper Includes:

• BTR-12 Battery Pack
• ADC-09A AC Adapter
• ACC-09 AC Power Cord (for ADC-09A)
• HEX-01 Hex Wrench
• BRS-02 Brush
• Instruction manual

Features:

• 3-second heating time with beep and LED notification
• Low pulling force for comfortable stripping
• Strips 200–400 μm coated fibers and ribbon fibers
• Ergonomic design for high fiber count applications
• Bluetooth®-capable for wireless connection to smartphones
• High-capacity battery supports ~600 stripping cycles

Specifications:

• Applicable optical fiber: Glass optical fibers, capillary
• Fiber count: 1-16
• Cladding diameter: 125μm (micron)
• Coating diameter: 200–400 μm
• Stripping length: up to 1.38" (35 mm)
• Typical heating time: 3 sec (5 sec in Eco mode)
• Heating temperature: 185–284 °F (85–140 °C)
• Fiber holders: FH-40, FH-50, FH-60, FH-70, FH-100 series (except FH-50-250 and FH-50-900)
• Wireless Connectivity: Bluetooth® 4.1 LE (Android 5.0+, iOS 8.0+, iPhone 6+)
• Dimensions: 6.12 × 1.92 × 1.45 in (155.5 × 48.7 × 36.8 mm)
• Weight: 9.35 oz (265 g, with battery)
• Battery:
  • Capacity: ~600 strips in Eco mode
  • Recharge time: ~2 hours from empty
  • Life: ~500 recharge cycles
