AFSI FS12 Pierside TAC-12 12-Channel Plug Fiber Optic Connector - 0.466" to 0.515" Cable

Amphenol Fiber Systems International’s (AFSI) FS12 fiber optic connector is engineered for harsh environments, including pierside, broadcast, and military applications. Available in both single mode and multimode versions, it utilizes field-proven MIL-PRF-29504 termini for reliable performance. Designed to meet the evolving needs of Navy communication systems both afloat and ashore, the 12-channel FS12 Pierside connector also supports high-density tactical broadcast networks.

Features:

• Hermaphroditic design allows plug-to-plug or plug-to-receptacle connections.
• Rugged design withstands harsh environmental and deployment conditions.
• Environmentally sealed connector for long-term reliability in demanding environments.
• MIL-PRF-29504/14 & /15-qualified termini support both single mode and multimode fiber types.
• Removable insert cap for easy cleaning of socket termini.
• Captive cap screw prevents loss during maintenance.
• Sealed termini protect the optical path in extreme conditions.
• Field-repairable with no additional components beyond the termini.

Applications:

• Ship-to-shore umbilical cables
• Broadcast networks
• U.S. military deployments: Army, Navy, Air Force, Marine Corps
• Oil, gas, and geoscience industries
• Industrial network environments

Specifications:

• Product Type: FS12 Pierside Plug
• Fiber Type: 62.5/125 multimode or 9/125 single mode
• Insertion Loss: 62.5/125 multimode fiber –0.3dB typical, 9/125 single mode fiber -0.4dB typical
• Operating Temperature: -46°C to +71°C (-50.8°F to 159.8°F)
• Finish: Hard anodize with PTFE, olive drab
• Cable Diameter: 0.466" - 0.515" (11.8mm - 13.0mm)

See Datasheet for more information
