    main product photo

    Broadcom Duplex Latching Connector, 1000µm (micron) Plastic Optical Fiber - Gray

    HFBR-4516

    Broadcom Duplex Latching Connector, Grey for 1000um plastic fiber
    - +
    View Quote Request Learn About Our Quote Tool
    The Broadcom duplex latching connector is designed for rugged applications requiring greater retention force than the nonlatching duplex connector. When inserting the duplex latching connector into a module, the connector latch mechanism should be aligned with the top surface of the dual combination of horizontal, vertical or tilted packages.

    Applications:
    • Industrial data links for factory automation and plant control
    • Intra-system links: board-to-board, rack-to-rack
    • Telecommunications switching systems
    • Computer-to-peripheral data links, PC bus extension
    • Proprietary LANs
    • Digitized video transmission
    • Medical instruments
    • Protection against lightning and voltage transients
    • High-voltage isolation
    Specifications:
    • Connector Style: Duplex Latching Connector with Crimp Ring
    • Fiber Type: Plastic Optical Fiber (POF) only
    • Color: Gray
    • Storage Temperature: -40°C to +85°C (-40°F to 185°F)
    • Operating Temperature: -40°C to +85°C (-40°F to 185°F)
    • Installation Temperature: 0°C to +70°C (32°F to 158°F)
    • Retention Force, Connector to Versatile Link Transmitters and Receivers:
      • Minimum: 50 N
      • Typical: 80 N @ +25°C (77°F)
    • Tensile Force, Connector to Cable:
      • Minimum: 14 N
      • Typical: 35 N
    • Insertion Force, Connector to Versatile Link Transmitters and Receivers:
      • Minimum: 22 N
      • Typical: 51 N
