Broadcom Parchment Duplex Connector, 1000µm (micron) Plastic Optical Fiber - Off-White

The Broadcom duplex connector provides convenient termination for duplex fiber optic cables and is keyed to prevent incorrect insertion into duplex-configured modules. This duplex fiber connector is compatible with various combinations of horizontal, vertical, or tilted modules, such as two horizontal transmitters, two vertical receivers, or a horizontal transmitter paired with a horizontal receiver. The duplex non-latching connector is available in parchment/off-white (part number HFBR-4506Z).

Applications:

• Industrial data links for factory automation and plant control
• Intra-system links: board-to-board, rack-to-rack
• Telecommunications switching systems
• Computer-to-peripheral data links, PC bus extension
• Proprietary LANs
• Digitized video transmission
• Medical instruments
• Protection against lightning and voltage transients
• High-voltage isolation

Specifications:

• Connector Style: Parchment Duplex
• Fiber Type: Plastic Optical Fiber (POF) only
• Color: Off-White
• Storage Temperature: -40°C to +85°C (-40°F to 185°F)
• Operating Temperature: -40°C to +85°C (-40°F to 185°F)
• Installation Temperature: 0°C to +70°C (32°F to 158°F)
• Broadcom Part #: HFBR-4506Z
• Retention Force, Connector to Versatile Link Transmitters and Receivers:
  • Minimum: 7 N
  • Typical: 12 N @ +25°C (77°F)
• Tensile Force, Connector to Cable:
  • Minimum: 14 N
  • Typical: 35 N
• Insertion Force, Connector to Versatile Link Transmitters and Receivers:
  • Minimum: 13 N
  • Typical: 46 N
