Amphenol 905 FiberGrip^® SMA Connector, 1400µm (micron) Stainless Steel Ferrule

The Amphenol 905 FiberGrip® SMA Connector provides an epoxy-free interconnect solution designed for efficiency and reliability with a standard tip ferrule. This two-piece connector is ideal for applications requiring precision and durability, including medical, data communications, industrial, and military markets. The SMA fiber connector ferrule is made from stainless steel allowing the ferrule to act as a heat sink, pulling the heat quickly from the fiber, when used.

Features:

• Optimized laser design prevents fiber optic connector heating and maximizes fiber power.
• Epoxy-free design eliminates curing time, speeds up production, and allows for easy rework.
• No crimping is required, simplifying manufacturing by removing the need for a crimp ferrule in the assembly or BOM.

Specifications:

• Ferrule Hole Size: 1400µm
• Stainless Steel Ferrule
• Tolerance: +15/-0um
• Application: Lower Power FiberGrip
• Attach without Epoxy: Yes - Collet with Presfit
• Ferrule Length: 9.804mm +.008 / -0.012 ( .385 +.0003 /-.0004" )
• Ferrule Outer Diameter (OD): 3.167 + .005 /- .002 mm (.1247 +.0002/-.0001")
• Crimp Ferrule: Crimp not supplied but fits into rear body
• Coupling Nut Type/Material: Knurled, Nickel-Plated Brass
• Boot Not Included
• Cap Model Number: 905-5173-02-MD
• Cap Color: Black
• Tether Loop: No
• Cap Slit: No
• Cap Logo: No
