Amphenol 905 SMA Connector, 375µm (micron) Stainless Steel Ferrule, Stepped Backshell, Hex Nut

The Amphenol 905 SMA Connector delivers high-performance connections for demanding medical applications. Constructed from stainless steel, it offers exceptional durability and optical performance while meeting stringent medical industry standards. The SMA connector features a stainless steel ferrule, hex coupling nut, and a modified back shell to resemble the AMP SMA connector.

Features:

• Quick connection and removal
• REACH and RoHS-compliant
• Available in male and multimode configurations
• Optional unassembled components for laser manufacturers
• Stainless Steel 303/304 bodies and ferrules
• Clip secures the coupling nut to the ferrule body

Specifications:

• Ferrule hole size: 375µm
• Special Design Technology: Longer Rear Body, Crimps onto the body
• Attachment Method: Aluminum Crimp
• Ferrule Length: 9.855 +.025/-.025 mm(.388 ± .001")
• Ferrule Outer Diameter (OD): 3.1699 + 0.0508 /-0.0254 mm (0.1248 +0.0001/-0.0002")
• Coupling Nut Type/Material: Stainless Steel Hex Nut
• Cap Style: T-Style
• Cap Slit: No
• Boot sold separately
