Amphenol FC Connector Plug-Style Attenuator, 15 dB, Flat Polish

The Amphenol FC Connector Plug-Style Attenuator is compact in size and provides a 15 dB attenuation value with a flat polish. Unlike traditional attenuators that rely on light scattering, this attenuator utilizes light absorption technology. This approach prevents light from scattering into the fiber cladding, which can otherwise be reflected back at the fiber optic connector interface.

By maintaining a set distance between the connector end face and the fiber interface, the design minimizes interference that could cause insertion loss variations as the wavelength changes.

Features/Benefits:

• Wavelength-independent for compatibility with multi-wavelength systems
• Polarization-insensitive performance
• Compact plug-style design fits easily into existing patch panels
• Meets Telcordia GR-910 standards

Specifications:

• Attenuation: 15 dB
• Back Reflection/Return Loss: Ultra Polish ≤ ‐55 dB
• Operating Temperature: ‐40°C to 80°C (-40°F to 176°F)
• Operating Wavelengths: 1310/1550 nm (center wavelength)
• Operating Band Pass: 1260–1360 nm and 1430–1580 nm
• Polarization-Dependent Loss (PDL): ≤ 0.2 dB
