Amphenol 905 High-Power FiberGrip^® SMA Connector, Damage Resistant, 1040µm (micron) Beryllium Copper Ferrule

The Amphenol 905 High-Power FiberGrip® SMA Connector provides a simple, epoxy-free interconnect solution for high-power optical applications. Engineered for efficiency and reliability, this two-piece SMA connector is perfect for industries requiring precision and durability, including medical, data communications, industrial, and military sectors.

This SMA fiber Connector is built for high-power applications and incorporates air gap ferrule technology. This technology eliminates energy-absorbing materials near the fiber end face, such as epoxies, connector materials, and coatings. The SMA connector ferrules also function as heat sinks, quickly drawing heat away from the fiber.

Features:

• Quick and safe epoxy-free termination.
• Designed for high-power medical laser delivery systems.
• Damage-resistant design keeps dirt and epoxy away from the fiber tip.
• Autoclave sterilizable for medical applications.
• Compatible with RFID-integrated technology.

Specifications:

• Ferrule Hole Size: 1040µm
• Ferrule: Beryllium Copper
• Special Design Technology: FiberGrip with Beryl Copper Ferrule
• Application: Holmium Lasers, High Power Lasers
• Ferrule Length: 9.90mm +/-.02 (.3897 +/- 0.0007 ")
• Ferrule Outer Diameter (OD): 3.167 + .005 /- .002 mm (.1247 +.0002/-.0001")
• Coupling Nut Type/Material: Knurled, Nickel-Plated Brass
• Cap Model #: 905-5173-01-MD
• Cap Color: Black
• Tether Loop: No
• Cap Slit: Yes
• Cap Logo: No
• Sterilization: Yes
