Amphenol 905 High-Power SMA Connector, Damage Resistant, Beryllium Copper Ferrule, 3mm Black Boot

The Amphenol 905 High-Power FiberGrip® SMA Connector offers a simple, epoxy-free interconnect solution for high-power optical applications. Designed for efficiency and reliability, this two-piece SMA connector is ideal for markets requiring precision and durability, including medical, data communications, industrial, and military sectors.

This damage-resistant SMA connector features a beryllium copper ferrule, which acts as a heat sink to rapidly dissipate heat from the fiber during use. A 3mm strain relief boot is included for added fiber optic cable protection.

Features:

• Quick and safe epoxy-free termination.
• Designed for high-power medical laser delivery systems.
• Damage-resistant design keeps dirt and epoxy away from the fiber tip.
• Autoclave sterilizable for medical applications.
• Compatible with RFID-integrated technology.

Specifications:

• Ferrule Hole Size: (128-1200µm)
• Special Design Technology: Air Gap Technology
• Application: High Power
• Tolerances:
  • 125µm to 149µm: +5/-0µm
  • 150µm to 249µm: +10/-0µm
  • 250µm to 1499µm: +15/-0µm
  • 1500µm to 2300µm: +25/-0µm
• Ferrule Length: 9.855 mm (.388")
• Ferrule Outer Diameter (OD): 3.167 mm (.1247")
• Ferrule Rear Inner Diameter (ID): 2.59 mm (0.102")
• Damage Resistant Depth: 1.75 ± .07 mm (.069 ± .003")
• Damage Resistant Inner Diameter (ID): 2.0 ± .07mm (.079 ± .003")
• Coupling Nut Type/Material: Knurled, Nickel-Plated Brass
• Boot Color/Type: Black, T-Style
• Boot Diameter: 2.84 mm (0.112") diameter.
• Boot Logo: Yes
• Cap Color/Type: Black, T-Style
• Tether Loop: No
• Cap Slit: No
• Cap Logo: No
