Amphenol LC Duplex Connector, Multimode, 127µm (micron) Ceramic Ferrule, 1.6-2.0mm Boot

Amphenol’s LC Duplex small form factor (SFF) fiber optic connectors offer a high-density, cost-effective solution for data communications networks. Utilizing the familiar RJ-45 latching mechanism, the LC connector is nearly half the size of the SC connector, making it ideal for high-density frames and patch panels. As network demands grow, LC fiber connector provide greater bandwidth in less physical space, ensuring efficient and reliable performance.

Features/Benefits:

• Time-tested zirconia ferrule
• RJ-45-style latch for quick installation with an audible click when locked
• Pull-proof design prevents signal interruptions
• Compact form factor increases density compared to standard connectors
• EIA/TIA-604 and IEC 61754 compliant

Specifications:

• 127µm Zirconia Ferrule
• Recommended Cable Diameter: 1.6/2.0mm
• Body/Clip: Beige
• Boot Color: White (1.6/2.0mm connector boot)
• Insertion Loss: ≤ 0.25dB typical (multimode)
• Return Loss: Ultra (UPC) ≤ -55dB (performance is polish dependent)
• Durability: < 0.2dB change over 500 mating cycles
• Operating Temperature: -40 to +75°C (-40°F to 167°F)
