Amphenol Singlemode Behind-the-Wall LC Connector, 125.5µm Ceramic Ferrule, 900µm Boot

Amphenol’s LC small form factor (SFF) fiber optic connectors offer a high-density, cost-effective solution for data communications networks. Utilizing the familiar RJ-45 latching mechanism, the LC connector is nearly half the size of the SC connector, making it ideal for high-density frames and patch panels. As network demands grow, LC fiber connectors provide greater bandwidth in less physical space, ensuring efficient and reliable performance.

Features:

• High-density, low-cost solution with no performance sacrifices
• RJ-45-style latch for quick installation with an audible click when locked
• The pull-proof design prevents signal interruptions
• Compact form factor increases density compared to standard connectors
• EIA/TIA-604 and IEC 61754 compliant

Specifications:

• 125.5µm Zirconia Ferrule
• Recommended Cable Diameter: 900µm
• Body/Clip: Behind-the-Wall Blue
• Boot Color: White (900µm connector boot)
• Insertion Loss: ≤ 0.15dB typical (singlemode)
• Return Loss: Ultra (UPC) ≤ -55dB (performance is polish dependent)
• Durability: < 0.2dB change over 500 mating cycles
• Temperature: <0.3dB change from -40 to +85°C (-40°F to 185°F)
