Amphenol Singlemode LC Connector, 125.5µm Ceramic Ferrule, 3mm White Boot

956-331-590314

Amphenol Single-Mode Simplex LC Connector, Zirconia Ferrule 125.5um Nominal Hole Size, with White Dust Cap, 3mm White Boot

Amphenol’s LC small form factor (SFF) fiber optic connectors offer a high-density, cost-effective solution for data communications networks. Utilizing the familiar RJ-45 latching mechanism, the LC connector is nearly half the size of the SC connector, making it ideal for high-density frames and patch panels. As network demands grow, LC fiber connectors provide greater bandwidth in less physical space, ensuring efficient and reliable performance.

Features:

High-density, low-cost solution with no performance sacrifices
RJ-45-style latch for quick installation with an audible click when locked
The pull-proof design prevents signal interruptions
Compact form factor increases density compared to standard connectors
EIA/TIA-604 and IEC 61754 compliant

Specifications:

125.5µm Zirconia Ferrule
Recommended Cable Diameter: 3mm
Body/Clip: Blue
Boot Color: Standard White (3mm connector boot)
Insertion Loss: ≤ 0.15dB typical (singlemode)
Return Loss: Ultra (UPC) ≤ -55dB (performance is polish dependent)
Durability: < 0.2dB change over 500 mating cycles
Temperature: <0.3dB change from -40 to +85°C (-40°F to 185°F)
