Amphenol FC Connector, Singlemode, APC, 125.5µm (micron) Ceramic Conical Ferrule, 2mm Green Boot - Tunable

The Amphenol Fiber Optic Ferrule Connector (FC) provides reliable optical fiber termination for applications such as telecommunications networks, monitoring systems, data centers, and test and measurement equipment. Its threaded coupling nut enhances pull-out performance while the internal cavity and epoxy injection tube ensure proper epoxy application, improving manufacturing yields and overall product reliability.

The single-mode FC/APC connector has a stainless steel body and a ceramic conical ferrule. It includes a 2 mm green strain relief boot for fiber optic cable protection. The tunable FC/APC connector features a tight-fit keyway that prohibits the possible mis-mating between FC/PC and FC/APC connectors.

Features:

• One-piece construction
• A non-optical disconnect feature design prevents signal interruption
• Teflon tube in the rear of the connector ensures clean epoxy injection
• Zirconia ferrules minimize insertion and return loss
• High-precision zirconia ferrules minimize insertion loss and return loss values
• IEC 61 Compliant

Specifications:

• Ferrule Size/Tolerance: 125.5 µm (+1/-0 µm)
• Ferrule Material: Ceramic (Zirconia)
• Body Material: Stainless Steel
• Nut Material: Nickel-Plated Brass
• Insertion Loss: .30 dB
• Return Loss: 65 dB
• Recommended Cable Diameter: 2 mm
• Boot Color: Green
• Sterilization: ETO/Autoclave
