Amphenol FC Connector, Singlemode, APC, 125.5µm (micron) Ceramic Conical Ferrule, 900µm Green Boot - Tunable

The Amphenol Ferrule Connector (FC) ensures reliable optical fiber termination across various network applications. It uses a threaded coupling nut to deliver enhanced pull-out performance. Its internal cavity and epoxy injection tube prevent improper epoxy application, improving manufacturing yields and product reliability.

The single-mode FC/APC connector has a stainless steel body and a ceramic conical ferrule. It includes a 900µm green strain relief boot for added fiber optic cable protection. The tunable FC/APC connector features a tight-fit keyway that prohibits the possible mis-mating between FC/PC and FC/APC connectors.

Features:

• One-piece construction
• A non-optical disconnect feature design prevents signal interruption
• Teflon tube in the rear of the connector ensures clean epoxy injection
• Zirconia ferrules minimize insertion and return loss
• High-precision zirconia ferrules minimize insertion loss and return loss values
• IEC 61 Compliant

Specifications:

• Ferrule Size/Tolerance: 125.5µm (+1/-0 µm)
• Ferrule Material: Ceramic (Zirconia)
• Body Material: Stainless Steel
• Nut Material: Nickel-Plated Brass
• Insertion Loss: .30 dB
• Return Loss: 65 dB
• Recommended Cable Diameter: 900µm
• Boot Color: Green
• Sterilization: ETO/Autoclave
