Amphenol LC Duplex Connector, Singlemode, 126µm (micron) Ceramic Ferrule, 1.6-2.0mm Boot

Amphenol’s LC small form factor (SFF) fiber optic connectors offer a high-density, cost-effective solution for data communications networks. Utilizing the familiar RJ-45 latching mechanism, the LC connector is nearly half the size of the SC connector, making it ideal for high-density frames and patch panels. As network demands grow, LC fiber connector provide greater bandwidth in less physical space, ensuring efficient and reliable performance.

Features/Benefits:

• Time-tested zirconia ferrule
• RJ-45-style latch for quick installation with an audible click when locked
• Pull-proof design prevents signal interruptions
• Compact form factor increases density compared to standard connectors
• EIA/TIA-604 and IEC 61754 compliant

Specifications:

• 126µm Zirconia Ferrule
• Recommended Cable Diameter: 1.6/2.0mm
• Body/Clip: Beige
• Boot Color: White (1.6/2.0mm connector boot)
• Insertion Loss: ≤ 0.15dB typical (singlemode)
• Return Loss: Ultra (UPC) ≤ -55dB (performance is polish dependent)
• Durability: < 0.2dB change over 500 mating cycles
• Operating Temperature: <0.3dB change from -40 to +85°C (-40°F to 185°F)
