ÅngströmBond® AB9015P Low Refractive Index Adhesive, UV Cure (3cc Syringe)

AB9015P-3CCA

ÅngströmBond® AB9015P Low Refractive Index adhesives, 3cc Automatic Cartridge

The ÅngströmBond^® AB9015P is a low refractive index optical adhesive with higher viscosities than typical materials of its kind. Designed as a gap-fill material, it can also be used for bonding glass, ceramics, and various high-tech plastics. Available in a 3cc epoxy syringe.

Physical Properties:

Viscosity @ 25°C: 4,500 cPs
Shore A Hardness: 70
Operating Temperature Range: -20°C to 120°C (degree celsius); -4°F to 248°F (degree Fahrenheit)
Refractive index: 1.33 @ 589nm

Handling Characteristics:

Cure Schedule: 100-300 mW/cm²- 15sec- 5min @ 320-390nm

See Datasheet for additional properties, storage and handling notes

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Datasheet

ÅngströmBond® AB9015P Low Refractive Index Adhesive, UV Cure (3cc Syringe) - Datasheet

SDS

ÅngströmBond® AB9015P Low Refractive Index Adhesive, UV Cure (3cc Syringe) - SDS
