ÅngströmBond^® AB9061 High Power Laser Adhesive, UV Cure (3cc Syringe)

The ÅngströmBond^® AB9061 High Power Laser Adhesive is a rigid, optically clear adhesive designed for bonding lenses and optical devices. It has successfully been used in high power applications where it is directly in the path of laser energy. Available in a 3cc epoxy syringe.

Additional Features:

• High viscosity polymer
• Good adhesion to glass and good release from metal molds.

Physical Properties:

• Viscosity @ 25°C: 9,000 cPs
• Glass Transition Temperature, Tg: 109°C (degree celsius); Tg: 228.2°F (degree Fahrenheit)
• Shore D Hardness: 87
• Cure Shrinkage: < 0.3%
• Coefficient of Thermal Expansion (CTE): Below Tg: 37 ppm/°C; Above Tg: 71 ppm/°C;
• Operating Temperature Range: -40°C to 140°C; -40°F to 284°F
• Refractive index:
  • 1.567 @ 589nm
  • 1.552 @ 1310nm
  • 1.548 @ 1550nm

Handling Characteristics:

• Cure Schedule: 100 mW/cm² - 5-20 sec @300 to 450 nm

See Datasheet for additional properties, storage and handling notes
