Dymax 5000-EC UV Curing Flood Lamp with Light Shield
39820
Dymax 5000-EC UV Curing Flood Lamp with Light Shield
The Dymax 5000-EC UV Epoxy Curing Flood Lamp System is designed for high-intensity, rapid UV curing of epoxy, adhesives, coatings, and inks. The 5000-EC UV curing lamp is ideal for processes requiring concentrated, high-intensity UV light in a narrow 5" x 5" area. These UV (ultraviolet) flood lamps deliver focused light primarily in the UV-A range (320-390 nm wavelength) to achieve maximum cure depths and "tack-free" results, typically within 10-30 seconds.
The Light Shield is designed to protect operators from UV and visible light while ensuring clear visibility of curing parts. As part of the flood lamp light-curing system, these shields offer 360° protection, allowing operators to safely observe the curing process.
Features:
The Light Shield is designed to protect operators from UV and visible light while ensuring clear visibility of curing parts. As part of the flood lamp light-curing system, these shields offer 360° protection, allowing operators to safely observe the curing process.
Features:
- Initial Intensity: 225 mW/cm²
- 5" x 5" (12.7 cm x 12.7 cm) epoxy curing area
- Rugged brushed-aluminum construction
- Typical cure times of 10-30 seconds
- Bulbs warranted for 2,000 hours
