Dymax OP-4-20655 Optical Adhesive, Fiber Optic Assembly, Optically Clear, UV Cure - 30ml Syringe

The Dymax OP-4-20655 Adhesive for Fiber Optic Assembly is a clear, low-shrinkage, UV/visible light-curable adhesive. Formulated as a very soft, shock-absorbing, low-modulus material, it is ideal for thermal cycling of fragile optical components. Dymax high-performance optical adhesives cure in seconds under UV or visible light, helping increase productivity, reduce assembly costs, and enhance operator safety. This fiber optic adhesive is fully compliant with RoHS Directive 2015/863/EU. Packaged in a 30 ml syringe.

Features:

• No Solvents Added
• Optically clear adhesive
• Fast, total cure in seconds with UV or visible light
• Recommended Surfaces: Glass, Ceramics, Plastics & Metals

Applications:

• Bonding and laminating
• Fiber optic couplings

Uncured Properties:

• Chemical Class: Urethane acrylate
• Appearance: Optically clear
• Solubility: Alcohols, ketones, chlorinated solvents
• Toxicity: Low
• Flash Point: >93°C (200°F)
• Viscosity: 800 cP (nominal)
• Shelf Life (at room temperature): 18 months

Cured Properties:

• Shore Hardness Durometer: 00–40
• Tensile at Break: 0.7 MPa (100 psi)
• Elongation at Break: 250%
• Modulus of Elasticity: 1.4 MPa (200 psi)
• Glass Transition Temperature, Tg: –57°C (-70.6°F)
• Thermal Range (brittle/degass): –55°C to +180°C (-67°F to 356°F)
• Refractive Index: 1.480
• Boiling Water Absorption (2 hours): 2.4%
• Water Absorption (24 hours, 25°C): 0.7%
• Linear Shrinkage: 1.9%
• Tensile Compression Shear (glass-to-glass): 200 psi

See datasheet for curing instructions and additional specifications
