EPO-TEK® HYB-353ND-HV High Viscosity Epoxy, Hybrid Heat & UV Cure - Pre-Mixed and Frozen 3cc Syringe (5-Pack Sample)

The EPO-TEK^® HYB-353ND-HV High Viscosity Epoxy is a single-component, high-temperature epoxy for semiconductor, hybrid, and fiber optic applications. It is formulated to deliver similar cured performance to EPO-TEK® 353ND, with modifications that allow for initial UV tacking. This product is a higher viscosity version of EPO-TEK HYB-353ND. Available in a 5-pack of premixed and frozen syringes (3 cc automatic dispensing syringes).

Recommended Cure: Initial Tack 100mW/cm² for 10 seconds @ 240-365 nm + 150°C (302°F)/30 Minutes Thermal Cure. Available in a 3cc syringe.

Features of HYB-353ND-HV:

• Supports active alignment of lenses, diodes, and optical components
• UV tacking for precise positioning
• High viscosity Newtonian
• Pot life: 2 Hours

Applications:

• Fiber Optics: Fiber bonding and component alignment
• Optoelectronics: Optical components, sub-assemblies; lens, diode, and component bonding
• Piezoelectric bonding
• LiDAR and IR Sensors

Physical Properties:

• Color (before cure): Light Yellow
• Consistency: Pourable liquid
• Viscosity (23°C) @ 10 rpm: 9,000-20,000 cPs
• Glass Transition Temperature, Tg: ≥ 100°C (≥ 212°F)
• Shore D Hardness: 80
• Coefficient of Thermal Expansion (CTE):
  • Below Tg: 48 x 10^-6 in/in°C
  • Above Tg: 143 x 10^-6 in/in°C
• Suggested Operating Temperature: < 300 °C (Intermittent); < 572°F

Optical Properties @ 23°C:

• Spectral Transmission:
  • ≥ 50% @ 550 nm
  • ≥ 95% @ 1,100-1,600 nm
  • ≥ 98% @ 800-1,000 nm
• Refractive Index: 1.5545 @ 589 nm (uncured)

See Datasheet for additional properties and application notes
