FiberSource MM SC Connector, 144um (3mm)

FS00239-144-30-BK

FiberSource Multimode SC Connector, Polymer Body, Ceramic Pre-Radius Ferrule 144um Nominal Hole Size, 3mm Black Strain Relief Boot.

FiberSource SC connectors meet or exceed industry standards, offering reliable performance for fiber optic networks. The SC fiber connector features a square design, a zirconia ferrule and a push-pull latching mechanism for quick, secure connections. This design enables fast, tool-free connections while supporting higher panel density compared to twist-and-screw connectors like ST, improving network reliability and data transmission speed.

Features:

FOCIS-3 Compliant
Meet Telcordia, EIA / TIA, IEC, and JIS C5973 Specifications
Durable glass-filled composite resin housing
Meets UL94-V0 flammability requirements
RoHS compliant

Specifications:

Ferrule Type: Ceramic (zirconia) ferrule
Ferrule ID Diameter: 144µm (micron)
Fiber Type: Multimode
Boot Colors: Black
Boot Size: 3mm
Insertion Loss: < 0.4dB
Temperature Stability: < 0.3dB; -40°C to 80°C (-40°F to 176°F)
