FiberSource FC Connector, APC, Singlemode, 125.5µm (micron) Ceramic Ferrule, 3mm Green Boot
FS01172-55-GR
FiberSource Single Mode FC/APC Simplex Connector, Metal body, Ceramic Pre-Angled Conical Ferrule, 125.5um Nominal Hole Size, 3.0mm Green Boot
FiberSource FC connectors meet or exceed industry standards, delivering reliable performance for fiber optic networks. The FC fiber connector’s screw-on design and alignment key make it well-suited for singlemode fibers. Its threaded coupling ensures a secure, high-quality connection, ideal for high-speed storage area networks (SANs).
Features:
Features:
- Meet Telcordia, EIA / TIA, IEC, and JIS C5970 Specifications:
- Preradiused Zirconia Ferrule
- Durable metal housing
- Strain Relief for 3.0mm Cable
- RoHS Complaint
- Ferrule Type: Ceramic (zirconia) Conical ferrule
- Ferrule ID Diameter: 125.5µm (micron)
- Fiber Type: Singlemode
- Boot: 3.0mm Bellcore Boot
- Boot Color: Green
- 3.0mm Crimp Ring and Eyelet
- Polish: APC (Angled Physical Contact), Pre-Angled 8° (degree)
- Insertion Loss: < 0.2 dB
- Return Loss: > 50 dB
- Durability: > 1,000 Matings
- Tensile Strength: > 20 lbs of force
- Flexure: > 100 Cycles
- Temperature Stability: -40°C to 80°C (-40°F to 176°F)
- Replaces p/n FS00225-55-GR
