FiberSource SC Connector, APC, Singlemode, 125.5µm (micron) Ceramic Ferrule, 3mm Green Boot
FS00217-55-GR
FiberSource Single Mode SC/APC Connector, Polymer Body, Ceramic Pre-Angled Cone Type Ferrule 125.5um Nominal Hole Size, 3mm Green Strain Relief Boot.
FiberSource SC connectors meet or exceed industry standards, offering reliable performance for fiber optic networks. The SC fiber connector features a square design, a zirconia ferrule and a push-pull latching mechanism for quick, secure connections. This design enables fast, tool-free connections while supporting higher panel density compared to twist-and-screw connectors like ST, improving network reliability and data transmission speed.
Features:
Features:
- FOCIS-3 Compliant
- Meet Telcordia, EIA / TIA, IEC, and JIS C5973 Specifications
- Durable glass-filled composite resin housing
- Meets UL94-V0 flammability requirements
- RoHS compliant
- Ferrule Type: Ceramic (zirconia) ferrule
- Ferrule ID Diameter: 125.5µm (micron)
- Fiber Type: Singlemode
- Polish: APC (Angled Physcial Contact)
- Boot Colors: Green
- Boot Size: 3mm
- Insertion Loss: < 0.25dB
- Return Loss: > 70dB
- Temperature Stability: < 0.3dB; -40°C to 80°C (-40°F to 176°F)
