Polymicro Hard Clad Silica Low-OH 940/1000/1035/1400 Fiber
JTFIH970100010351400
Polymicro Hard Clad Silica Low-OH 940/1000/1035um Fiber with a 1400um Blue Tefzel Buffer for Vis-NIR Transmission (380nm to 2200nm). 0.22 NA
- Step Index
- Numerical Aperture: 0.22 ± 0.02
- Full Acceptance Cone: 25.4 degrees
- Vis-NIR Transmission, 380nm to 2,200nm
- Radiation Resistant
- High Laser Damage Threshold
- Sterilizable
- Bio-compatible Materials – USP Class VI*
- Low-OH Silica Core, Doped Silica Clad
- Hard Polymer Secondary Cladding
- Standard Buffer: Blue Tefzel and Other Colors Available
- Custom Buffer: Acrylate, Nylon or Hytrel
- Temperature: Operating -65ºC to +125ºC
- High -OH and Custom Sizes Available
- Proof Tested to 100kpsi
- Numerical Aperture: 0.22 ± 0.02
- Full Acceptance Cone: 25.4 degrees
- Vis-NIR Transmission, 380nm to 2,200nm
- Radiation Resistant
- High Laser Damage Threshold
- Sterilizable
- Bio-compatible Materials – USP Class VI*
- Low-OH Silica Core, Doped Silica Clad
- Hard Polymer Secondary Cladding
- Standard Buffer: Blue Tefzel and Other Colors Available
- Custom Buffer: Acrylate, Nylon or Hytrel
- Temperature: Operating -65ºC to +125ºC
- High -OH and Custom Sizes Available
- Proof Tested to 100kpsi
