Polymicro Silica/Silica High-OH 600/660/710 Fiber
FVP600660710
Polymicro Silica/Silica High-OH 600/660um Fiber with a 710um Polyimide Buffer for UV-Vis-NIR Transmission (180nm to 1150nm). 0.22 NA
- New Tighter Tolerances!
- Step Index
- Numerical Aperture: 0.22 ± 0.02
- Full Acceptance Cone: 25.4 degrees
- UV-Vis-NIR Transmission, 180nm to 1,150nm
- Superior Radiation Resistant
- High Laser Damage Threshold
- Sterilizable
- Bio-compatible Materials – USP Class VI*
- High -OH Silica Core, Doped Silica Clad
- Polyimide Buffer Standard; Silicone, Acrylate, Fluoropolymer, Aluminum & dual buffers also available
- Polyimide Concentricity ± 3µm
- Sizes for Bundling
- Tighter Tolerances Available
- Temperature: Operating –65ºC to +300ºC
- Intermittent, up to 400ºC
- Proof Tested to 100kpsi
- Step Index
- Numerical Aperture: 0.22 ± 0.02
- Full Acceptance Cone: 25.4 degrees
- UV-Vis-NIR Transmission, 180nm to 1,150nm
- Superior Radiation Resistant
- High Laser Damage Threshold
- Sterilizable
- Bio-compatible Materials – USP Class VI*
- High -OH Silica Core, Doped Silica Clad
- Polyimide Buffer Standard; Silicone, Acrylate, Fluoropolymer, Aluminum & dual buffers also available
- Polyimide Concentricity ± 3µm
- Sizes for Bundling
- Tighter Tolerances Available
- Temperature: Operating –65ºC to +300ºC
- Intermittent, up to 400ºC
- Proof Tested to 100kpsi
