Seikoh Giken LC Connector, Multimode, 126µm (micron) Ceramic Ferrule, 900µm Boot - Tunable

Seikoh Giken LC small form factor (SFF) fiber optic connectors offer a high-density, cost-effective solution for data communications networks. Utilizing the familiar RJ-45 latching mechanism, the LC connector is nearly half the size of the SC connector, making it ideal for high-density frames and patch panels. As network demands grow, LC fiber connector provide greater bandwidth in less physical space, ensuring efficient and reliable performance.

Features:

• Quick assembly and high-performance design
• Compliant with IEC 61754-20 and JIS C 5964-20 standards
• Meets Telcordia GR-326-CORE test specifications (with slotted boot)

Specifications:

• Model Number: SLC-PQ1G
• Housing Color: Aqua
• Ferrule Size: 126µm (micron)
• Zirconia Ferrule
• Boot Color: Light Gray
• Boot I.D.: For 0.9mm buffered fiber
• Tunable after assembly
• White Dust Cap
• Marking of Boot: SG
