Seikoh Giken LC Connector, Singlemode, APC, 125µm (micron) Ceramic Ferrule, 900µm Green Boot

SLC-PN1G-811251F314G

Seikoh Giken Gold Standard Single Mode LC/APC Connector, Green Polymer Body, Ceramic Pre-Radius Ferrule 125um Nominal Hole Size, 900um Green Strain Relief Boot.

SEE P/N SLC-PN1G-811251F304G FOR TUNABLE VERSION

Seikoh Giken LC small form factor (SFF) fiber optic connectors offer a high-density, cost-effective solution for data communications networks. Utilizing the familiar RJ-45 latching mechanism, the LC connector is nearly half the size of the SC connector, making it ideal for high-density frames and patch panels. As network demands grow, LC fiber connector provide greater bandwidth in less physical space, ensuring efficient and reliable performance.

Features:

Quick assembly and high-performance design
Compliant with IEC 61754-20 and JIS C 5964-20 standards
Meets Telcordia GR-326-CORE test specifications (with slotted boot)

Specifications:

Model Number: SLC-PN1G
Ferrule Size: 125µm (micron)
Zirconia Ferrule
Boot Color: Green
Boot I.D.: For 0.9mm buffered fiber
Tunable after assembly
White Dust Cap
Marking of Boot: SG
