    main product photo

    Seikoh Giken Pre-Radius 4 Slot Zirc. 2.5mm Ferrule 125.5um

    SZ-3A1412F80G

    Seikoh Giken Pre-Radius SM 4 Slot Zirconia 2.5mm Ferrule with a 125.5um Inner Diameter and a 1.0um Concentricity Tolerance
    - +
    View Quote Request Learn About Our Quote Tool
    Seikoh Giken’s 2.5mm zirconia ferrules are designed for singlemode applications using SC and FC connectors. Each ferrule features a pre-dome shape that simplifies alignment and improves polish consistency.

    These ferrules are manufactured through a precision injection molding process that results in a dense, uniform ceramic structure and a smooth surface finish—key for maintaining low insertion loss. The tapered tail design helps guide the fiber into place without scratching, making handling and assembly easier.

    Features & Benefits:
    • Precision injection-molded for high-density zirconia and superior surface quality
    • Pre-angled, conical design tailored for APC applications
    • Smooth taper tail for easy fiber insertion without scratches
    • End-to-end process control ensures reliable performance
    • Ideal for SC and FC connector types
    Specifications:
    • Ferrule Hole Diameter: 125.5µm (micron)
    • Ferrule Type: Ceramic (Zirconia) Ferrule
    • Polish Type: Physical Contact (PC)
    • Hole Eccentricity: ≤ 0.5μm
    • Hole Diameter Tolerance: + 1.0/-0
    • Flange Shape: Standard
    • Flange Type: Stainless Steel

    Datasheet
