Seikoh Giken SFP-550 IPC APC 40-Port 2.5mm Step Ferrule SC/FC Connector Holder, 1.3mm Flange

The Seikoh Giken SFP-550 IPC APC Step Ferrule Holder is designed to securely and precisely hold 2.5mm ferrules (SC and FC connectors) with a 1.3mm flange thickness in place during polishing. The holder accommodates up to 40 ferrules at once, improving efficiency in high-volume polishing. It is compatible with Seikoh Giken SFP-550 Fiber Optic Polishing Machines, ensuring consistent results for demanding applications.

The Independent Pressure Control (IPC) technology applies even pressure to each ferrule, regardless of its protrusion length, ensuring stable, high-quality output. Unlike most ferrule holders that require connectors to be placed symmetrically for even polishing, the IPC plate delivers consistent results even when ferrules are placed randomly.

Specifications:

• Holder Model: SFP-550 IPC APC
• Ferrule Size: 2.5mm Step
• Fiber Optic Connector Types: SC, FC
• Capacity: 40 ferrules
• Seikoh Giken plates are interchangeable between the following polishing machines: SFP-550C, SFP-560A3, and SFP-560A3C.
• Flange Size: 1.3mm
