Seikoh Giken SFP-550 IPC 24-Port Conical Ferrule SC/APC Connector Holder, 35° Chamfer Angle
PH55-CP8C-24
Seikoh Giken SFP-550 24 Position Conical SC/APC Independent Pressure Control (IPC) Connector Holder (35 degree chamfer angle application)
The Seikoh Giken SFP-550 IPC Conical Ferrule Connector Holder is designed to securely and precisely hold SC/APC connectors in place during polishing. The holder accommodates up to 24 connectors at once and is tailored for polishing ferrules with a 35° chamfer angle. It is compatible with Seikoh Giken SFP-550 Fiber Optic Polishing Machines, ensuring consistent results for demanding applications.
The Independent Pressure Control (IPC) technology applies even pressure to each ferrule, regardless of its protrusion length, ensuring stable, high-quality output. Unlike most ferrule holders that require connectors to be placed symmetrically for even polishing, the IPC plate delivers consistent results even when ferrules are placed randomly.
Specifications:
The Independent Pressure Control (IPC) technology applies even pressure to each ferrule, regardless of its protrusion length, ensuring stable, high-quality output. Unlike most ferrule holders that require connectors to be placed symmetrically for even polishing, the IPC plate delivers consistent results even when ferrules are placed randomly.
Specifications:
- Holder Model: SFP-550 IPC
- Fiber Optic Connector Types: SC/APC
- Capacity: 24 connectors
- Seikoh Giken plates are interchangeable between the following polishing machines: SFP-550C, SFP-560A3, and SFP-560A3C.
- Chamfer Angle: 35° (degree)
