Seikoh Giken SFP-550 IPC 18-Port 2.0mm Narrow Key Conical Ferrule FC/APC Connector Holder, 35° Chamfer Angle

The Seikoh Giken SFP-550 IPC FC/APC Conical Ferrule Connector Holder is designed to securely and precisely hold 2.0mm Narrow Key FC/APC connectors in place during polishing. The holder accommodates up to 18 connectors at once and is tailored for polishing ferrules with a 35° chamfer angle. It is compatible with Seikoh Giken SFP-550 Fiber Optic Polishing Machines, ensuring consistent results for demanding applications.

The Independent Pressure Control (IPC) technology applies even pressure to each ferrule, regardless of its protrusion length, ensuring stable, high-quality output. Unlike most ferrule holders that require connectors to be placed symmetrically for even polishing, the IPC plate delivers consistent results even when ferrules are placed randomly.

Specifications:

• Holder Model: SFP-550 IPC
• Ferrule Size: 2.0mm Narrow Key Conical
• Fiber Optic Connector Types: FC/APC
• Capacity: 18 connectors
• Seikoh Giken plates are interchangeable between the following polishing machines: SFP-550C, SFP-560A3, and SFP-560A3C.
• Chamfer Angle: 35° (degree)
