Seikoh Giken SFP-550 IPC 24-Port 2.1mm Wide Key Conical Ferrule FC/APC Connector Holder, 35° Chamfer Angle

The Seikoh Giken SFP-550 IPC Connector Holder is designed to securely and precisely hold 2.1mm Wide Key Conical Ferrule FC/APC connectors in place during polishing. The holder accommodates up to 24 connectors at once and is tailored for polishing ferrules with a 35° chamfer angle. It is compatible with Seikoh Giken SFP-550 Fiber Optic Polishing Machines, ensuring consistent results for demanding applications.

The Independent Pressure Control (IPC) technology applies even pressure to each ferrule, regardless of its protrusion length, ensuring stable, high-quality output. Unlike most ferrule holders that require connectors to be placed symmetrically for even polishing, the IPC plate delivers consistent results even when ferrules are placed randomly.

Specifications:

• Holder Model: SFP-550 IPC
• Ferrule Size: 2.1mm Wide Key Conical
• Fiber Optic Connector Types: FC/APC
• Capacity: 24 connectors
• Seikoh Giken plates are interchangeable between the following polishing machines: SFP-550C, SFP-560A3, and SFP-560A3C.
• Chamfer Angle: 35° (degree)
