SENKO FC Connector, APC, Singlemode, 125µm (micron) Ceramic Conical Ferrule, 900µm Green Boot

SENKO’s Premium FC Connector features a vibration-resistant threaded coupling that surpasses GR-326-CORE standards and meets IEC 61753-1 Grade B random mating requirements. Designed for high-performance single-mode applications, it offers exceptionally low insertion loss, with a typical value of 0.05 dB against the master. A four-direction tuning ferrule enhances random mating performance, and the connector supports 900 µm cable diameters. The Premium FC fiber connector is ideal for applications requiring top-tier quality, performance, and reliability.

Features and Benefits:

• Vibration-resistant threaded coupling
• High mechanical stability
• Precision-aligned zirconia ferrule
• Low insertion loss (IL) and return loss (RL)
• Easy termination and environmental protection
• RoHS and REACH compliant

Specifications:

• Singlemode Fiber Optic Connector
• Ferrule ID Size: 125µm (micron)
• Ceramic (Zirconia) Conical Ferrule
• Polish: APC (Angled Physical Contact)
• Fiber Count: Simplex (1 Fiber)
• Boot size: 900µm (micron)
• Boot Color: Green
• Typical Insertion Loss:
  • Low Loss - 0.07 dB
  • Standard - 0.1 dB
• Max Insertion Loss:
  • Low Loss - 0.15 dB
  • Standard - 0.25 dB
• Typical Return Loss: ≥ 65 dB
• Durability: < 0.1 dB typical change, 500 matings
• Operational Temperature: -40°C to +75°C (-40°F to 167°F)
