SENKO LC Duplex Connector, Singlemode, 125.5µm (micron) Ceramic Ferrule, 2mm White Boot

The SENKO Standard 2PC LC Duplex Connector features a two-piece design for robust, easy installation in factory and field settings. It supports Singlemode fibers with low insertion loss and high return loss, making it ideal for telecommunications, data centers, FTTH, LANs, and medical applications. Its compact size suits high-density environments and complies with IEC 61754-20 standards.

The modular design allows for quick, tool-free termination, reducing downtime and enabling scalable network expansion. With high durability and performance, the SENKO LC Connector ensures reliable fiber optic connectivity in demanding conditions.

Features:

• Cost-effective solution
• Precision 1.25mm Ferrules for superior performance
• Compact design for high-density applications
• Fully compliant to IEC 61754-20
• User-friendly design for straightforward installation and maintenance

Specifications:

• 125.5μm Ferrule Inner Diameter
• Ceramic Ferrule (Zirconia)
• Connector Housing Color: Blue
• Typical Insertion Loss (dB): 0.12
• Max Insertion Loss (dB): 0.30
• Typical Return Loss (dB): ≥55
• Operating Temperature: -40°C to +75°C (-40°F to 167°F)
• Durability: White 2.0mm Boot
