SENKO MU Connector, Singlemode, 125.5µm (micron) Ceramic Ferrule, 1mm Blue Boot

SENKO One-Piece Singlemode MU Connectors are engineered to reduce termination time and improve yield in the field. These fiber optic connectors feature a pre-assembled body and precision-molded plastic housing, making them ideal for fast, reliable, and permanent terminations across a wide range of environments.

The MU fiber connector's free-floating zirconia ferrule is designed independently from the backbone, ensuring that cable tension doesn’t break contact between mated ferrules. With a precision screw-machined body and UL-rated housing and boot, these connectors deliver consistent performance and durability.

Features:

• Push-pull locking mechanism
• 1.25 mm zirconia precision ferrules
• Compact, high-density design
• Tunable ferrule
• Pull-proof design
• NTT and JIS compliant
• REACH and RoHS compliant

Applications:

• Data center
• Telecommunications
• LAN (Local Area Networks)
• CATV (Cable Television)
• Network transmission and switching equipment

Specifications:

• Ferrule Diameter: 125.5µm (micron)
• Ferrule Material: Ceramic (Zirconia)
• Fiber Count: Simplex (1 Fiber)
• Durability: 500 matings
• Housing Color: Brown
• Boot Type: 1.0mm Fiber
• Boot Color: Blue
• Typical Insertion Loss: 0.1 dB
• Max Insertion Loss: 0.2 dB
• Typical Return Loss: ≥ 55 dB
• Operating Temperature: -40°C to +75°C (-40°F to 167°F)
