Precision Fiber Products FC Connector, APC, Singlemode, 80µm (micron) Ceramic Conical Ferrule, 900µm Green Boot

SMCON1007C080-9

Single Mode FC/APC Connector, Metal Body, Ceramic Pre-Angled Conical Ferrule 80um Nominal Hole Size, 900um Green Strain Relief Boot.

Precision Fiber Products FC Singlemode Connectors are engineered for high-performance applications, including storage area networks (SANs). These FC fiber connectors feature a screw-on design and alignment key, making them ideal for singlemode fibers. The threaded coupling provides a secure, low-loss connection that supports high-speed data transmission.

Features:

Pre-assembled with pre-radiused, pre-polished ferrules
Pre-domed ceramic zirconia ferrules
Suitable for high-speed production polishing
Complies with IEC, TIA, and Telcordia standards
Conforms to JIS C5973 standard (F04 type connector)
PFP Part #: SM-CON1007C-0800

Specifications:

Connector Type: FC
Ferrule Inner Diameter: 80µm (micron)
Ferrule Type: Ceramic (Zirconia ZrO₂) Conical
Boot: PVC
Boot Size: 900µm
Boot Color: Green
Body: Nickel Plated Brass
Polish Type: Angled Physical Contact (APC)
Concentricity: <1µm
Operating Temperature: -25°C to 70°C (-13°F to 158°F)
