LightTube 3.8mm Round Breakout Tubing - PVC Plenum / 2.7x2.1mm Polypropylene - Yellow
B38627021YE00
LightTube 3.8mm Round Breakout Tubing with PVC Plenum Outer Jacket and 2.7x2.1mm Polypropylene Inner Tube for 24-Fiber 250μm bundles - Yellow
1524 Meter Standard Reel Length / $49.00 Cut Charge for Lengths < 1524 Meters
1524 Meter Standard Reel Length / $49.00 Cut Charge for Lengths < 1524 Meters
Opticonx LightTube™ 3.8mm Breakout Tubing is used for breaking out 250μm or 900μm buffered fiber to 3.8mm breakouts for terminating with any industry standard fiber optic connector. The tubing is constructed with an inner tube for the inserted fiber, a layer of aramid yarn for stain relief and connector crimping and a color coded jacket.
Features:
Features:
- Smooth fiber insertion
- Low shrinkage
- RoHS & REACH compliant
- Custom print legends and striping available
- Length markers available
- Pull string available
- Jacket Material: PVC Plenum
- Jacket Color: Yellow
- Inner Tube Material: Polypropylene
- Inner Tube OD x ID mm: 2.7mm x 2.1mm
- Operating Temperature: -20°C to +70°C (-4°F to 158°F)
- Shrinkage @ 85°C: < 2%
- Min Bend Radius, Installation: 7.6 cm
- Min Bend Radius, Service: 3.8 cm
- Weight: 12.5kg/km
