ÅngströmBond^® AB9098MV Optical Adhesive, UV Cure (3cc Syringe)

The ÅngströmBond^® 9098MV is a higher viscosity, slightly thixotropic version of 9098. It is a clear, yellow-resistant, UV cure optical adhesive designed for bonding glass, ceramics, metals and most plastics. Available in a 3cc epoxy manual syringe.

Additional Features:

• Low shrinkage adhesive offers a high Tg without the need for a heat post cure.
• Withstands 85/85 testing (damp heat testing or temperature humidity testing)
• Excellent for temperature cycling applications.

Physical Properties:

• Viscosity @ 25°C: 5,600 cPs
• Glass Transition Temperature, Tg: 105°C (degree celsius); Tg: 221°F (degree Fahrenheit)
• Shore D Hardness: 72
• Coefficient of Thermal Expansion (CTE): 52/°C
• Operating Temperature Range: -55°C to 180°C; -67°F to 356°F
• Refractive index: 1.48

Handling Characteristics:

• Cure Schedule: 150-300 mW/cm²- 5-15 sec. @320-480nm

See Datasheet for additional properties, storage and handling notes
