ÅngströmBond® AB9098MV Optical Adhesive, UV Cure (3cc Syringe)
AB9098MV-3CC
ÅngströmBond® AB9098MV High Strength UV Optical Adhesive, 3cc Manual Syringe
*Must be ordered in increments of 10*
*Must be ordered in increments of 10*
The ÅngströmBond® 9098MV is a higher viscosity, slightly thixotropic version of 9098. It is a clear, yellow-resistant, UV cure optical adhesive designed for bonding glass, ceramics, metals and most plastics. Available in a 3cc epoxy manual syringe.
Additional Features:
Additional Features:
- Low shrinkage adhesive offers a high Tg without the need for a heat post cure.
- Withstands 85/85 testing (damp heat testing or temperature humidity testing)
- Excellent for temperature cycling applications.
- Viscosity @ 25°C: 5,600 cPs
- Glass Transition Temperature, Tg: 105°C (degree celsius); Tg: 221°F (degree Fahrenheit)
- Shore D Hardness: 72
- Coefficient of Thermal Expansion (CTE): 52/°C
- Operating Temperature Range: -55°C to 180°C; -67°F to 356°F
- Refractive index: 1.48
- Cure Schedule: 150-300 mW/cm2- 5-15 sec. @320-480nm
