Arden nPA-600 Software Plugin - Panda PM Fibers

NPA-SPI01

Arden nPA-600 Software Plugin for measurement of RI and geometry of Panda-style PM Fibers

Expand the capabilities of the Arden nPA-600 Optical Refractive Index Profiler with our advanced software plug-in, designed to measure the fiber geometry of Panda-style PM fibers with cladding diameters ranging from 80 to 400 μm.

The SPI-01 plug-in provides precise measurements of:

Cladding: diameter, non-circularity, average refractive index
Core: diameter, non-circularity, average refractive index
Stress Rods: diameter, non-circularity, average refractive index
Concentricity: core-clad, core stress rod
Stress Rod Line offset to core and cladding

Skip to the end of the images gallery

main product photo

Skip to the beginning of the images gallery

Arden nPA-600 Software Plugin - Panda PM Fibers - Datasheet
