Seikoh Giken APC Pre-Angled 4 Slot Zirc 2.5mm Ferrule 126um
SNZ-3A1412600G
Seikoh Giken SM APC Pre-Angled Conical 4 Slot Zirconia 2.5mm Ferrule with a 126um Inner Diameter and a 0.5um Concentricity Tolerance
Seikoh Giken’s 2.5mm singlemode zirconia ferrules feature a conical, pre-angled design optimized for SC and FC APC connectors. Manufactured through a precision injection molding process, these ferrules deliver a high-density molecular structure and ultra-smooth surface for minimal signal loss and exceptional performance.
A smooth, tapered tail design allows for easy fiber insertion with reduced risk of scratching. Consistency is maintained throughout the entire manufacturing process—from molding and machining to final inspection—ensuring top-tier quality and reliability.
Features & Benefits:
A smooth, tapered tail design allows for easy fiber insertion with reduced risk of scratching. Consistency is maintained throughout the entire manufacturing process—from molding and machining to final inspection—ensuring top-tier quality and reliability.
Features & Benefits:
- Precision injection-molded for high-density zirconia and superior surface quality
- Pre-angled, conical design tailored for APC applications
- Smooth taper tail for easy fiber insertion without scratches
- End-to-end process control ensures reliable performance
- Ideal for SC/FC/APC connector types
- Applicable housings: SSC-PN1, 2, 3 (SC type), SNP-2, 5 (FC type)
- Ferrule Hole Diameter: 126µm (micron)
- Ferrule Type: Ceramic (Zirconia)
- Polish Type: Angled Physical Contact (APC)
- Hole Eccentricity: ≤ 0.5μm
- Hole Diameter Tolerance: + 1.0/-0
- Flange I.D.: 1.0mm
- Flange Shape: Standard
- Flange Type: Stainless Steel
